Samsung Windfree 1.0hp Inverter Aircond AR10BYFAMWKNME & AR10BYFAMWKXME Samsung WindFree Deluxe ((Smart Control)) R32 Inverter Air Conditioner
RM 1,739.00 RM 2,099.00
or 3 payments of RM 579.67 with
Capacity
● Capacity (Cooling, Btu/hr) : 21500 Btu/hr
● Capacity (Cooling, Min – Max, Btu/hr) : 5,000 ~ 25,000 Btu/hr
● Capacity (Cooling, kW) : 6.30 kW
● Capacity (Cooling, Min – Max, kW) : 1.47 ~ 7.33 kW
Energy Efficiency
● EER (Cooling, W/W) : 3.32 W/W
● EER (Cooling, Btu/hW) : 11.32 Btu/hW
● CSPF4.60
● Energy Efficiency Class for cooling (Grade) : 4★
Noise Level
● Noise Level (Indoor, High/Low, dBA) : 45 / 30 dBA
● Noise Level (Outdoor, High/Low, dBA : )52 dBA
Electrical Data
● Power Source(Φ/V/Hz) : 1 / 220-240 / 50
● Power Consumption(Cooling, W) : 1900 W
● Operating Current(Cooling, A) : 8.7 A
Physical specification
● Gross Dimension (Indoor, WxHxD) : 1115*290*375 mm
● Gross Dimension (Outdoor, WxHxD) : 1023*724*413 mm
● Net Dimension (Indoor, WxHxD) : 1055*299*215 mm
● Net Dimension (Outdoor, WxHxD) : 880*638*310 mm
● Gross Weight (Indoor, kg) : 13.4 kg
● Gross Weight (Outdoor, kg) : 39.7 kg
● Net Weight (Indoor, kg) : 11.8 kg
● Net Weight (Outdoor, kg) : 36.7 kg
● Loading Quantity (20/40/40Hft without Pipe) : 65 / 138 / 154
Technical Information
● Piping Length (Max, m) : 20 m
● Piping Height (Max, m): 12 m
● SVC Valve (Liquid (ODxL): 6.35
● SVC Valve (Gas (ODxL)) : 15.88
● Moisture Removal (l/hr) : 2.5 l/hr
● Air Circulation (Cooling, ㎥/min) : 18.6 ㎥/min
● Refrigerant (Type) : R32
● Refrigerant (Charging, kg) : 0.8 kg
● Refrigerant (Charging, tCO2e) : 0.54 tCO2e
● Low Ambient (Cooling, ℃) : 16~46 ℃
● Outdoor Unit (Compressor Type : BLDC
● Outdoor Unit (Anti-Corrosion Fin : Yes
Air Flow
● WindFree Cooling : Yes
● Air Direction Control (Up/Down): Auto
● Air Direction Control (Left/Right): Auto
● Air Flow Control Step (Cool/Fan): 5/4
Air Purification
● PM 1.0 Filter: No
● Tri Care Filter: No
● Easy Filter Plus (Anti-Bacteria): Yes
● Auto Clean (Self Cleaning): Yes
Convenience
● SmartThings : Yes
● AI Auto Cooling : Yes
● Motion Detect Sensor : No
● Freeze Wash : No
● Filter Cleaning Indicatior : Yes
● Indoor Temp. Display : Yes
● Display On/Off : Yes
● Beep On/Off : Yes
● 24-Hour Timer: Yes
● Auto Changeover : No
● Auto Restart : Yes
Operating Mode
● Auto Mode: Yes
● Fast Cool: Yes
● Good Sleep : Yes
● Eco Mode : Yes
● Dehumidification : Yes
● Fan Mode : Yes
● Quiet : Yes
Smart
● WiFi Embedded : Yes
